Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm

A Fiber Optic Multimode Patch Cord (also called a multimode fiber jumper) is a short, flexible cable with connectors on both ends, used to connect optical devices in high-speed data communication networks. It is designed for short-distance, high-bandwidth applications, commonly found in data centers, LANs (Local Area Networks), and enterprise networks.

Specification:

Features:

1.1 Fiber Type – OM1, OM2, OM3, OM4, or OM5 (supporting different bandwidths and distances):
OM1 (62.5µm) – Up to 275m @ 1Gbps
OM2 (50µm) – Up to 550m @ 1Gbps
OM3 (50µm, laser-optimized) – Up to 300m @ 10Gbps
OM4 (50µm, enhanced bandwidth) – Up to 400m @ 10Gbps
OM5 (50µm, wideband multimode) – Supports SWDM for 40G/100G

1.2 Core Diameter – Typically 50µm or 62.5µm, allowing multiple light modes to propagate.

1.3 Jacket Types –
PVC (general indoor use)
LSZH (Low Smoke Zero Halogen) – For fire safety in data centers
Armored – Extra protection in harsh environments

Application:

2.1 Telecommunication Network

2.2 Fiber Broad Band Network

2.3 CATV system

2.4 LAN and WAN system

2.5 FTTP
